ModelMPE-6501-ACAAB
ATX VersionATX 12V V2.52
PFCActive PFC
Input Voltage100-240V
Input Current10-5A
Input Frequency50-60Hz
Dimensions (L x W x H)140 x 150 x 86 mm
Fan Size120mm
Fan BearingHDB
Fan Speed2400 RPM
Noise Level @ 20%11.06 dBA
Noise Level @ 50%22.3 dBA
Noise Level @ 100%41.3 dBA
Efficiency85% Typically
80 PLUS Rating80 PLUS Bronze
ErP 2014 Lot 3Yes
Operating Temperature40°C
Power Good Signal100 - 500 ms
Hold Up Time>18ms at 100% Full Load@230Vac
MTBF>100,000 Hours
ProtectionsUVP / OVP / OPP / OTP / SCP
RegulatoryCCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
ATX 24 Pin Connectors1
EPS 4+4 Pin Connectors1
EPS 8 Pin Connector1
SATA Connectors8
Peripheral 4 Pin Connectors4
PCI-e 6+2 Pin Connectors4
SeriesMWE Bronze Series
Category500 to 750W
ModularNon Modular
80 Plus EfficiencyBronze
Form FactorATX
Watts650W
